Online Control Panel
The control panel is used to display and execute product functions. Users can control smart devices through the panel remotely.
This picture is an example of a mobile phone control interface. If you want to experience how the mobile phone controls this product.
Please use the "Tuya Smart" App to scan the QR code.
Tuya Smart-Me-Top Right Corner
Configure Device Panel
After OEM products,you can design and develop panels as needed,or you can use a wealth of custom components to configure beautiful and easy-to-use panels.
• APP compatible iOS & Android, with 2.4GHz Wi-Fi, for control of functions & weekly programming. Possible to share device with several people. Voice control compatible with Alexa and Google.
• Electronic control and RC, with display of functions and room °C.
• Functions: Heat/Cool/Dehumidifier/Fan.
• Modes: Normal/Sleep.
• Fan settings: High/Med/Low.
• Timer (24h max) programs Starting and/or Shut-off.
• Adjustable room temp.
• Automatic swing louvers.
• Window kit: extensible pipe 15x145cm (DxL max), and window adapter 124-184cm (L min-max).
• Air filters.
• Base with castors, with water collection tray with drainage valve.
• Rated power capacity: Cool 12000BTU (3,53kW) / Heat 8800BTU (2,58kW).
• Rated power input: Cool 1357W / Heat 1020W
• Energy efficiency index: EER 2,6 / COP 2,3
• Energy label class: Cool A / Heat A
• Airflow: 400m³/h
• Gas: R290 (230g)
• Dehumidify capacity: 28 L/day
• Noise: 65dB(A)
• Use temperature 7-35°C
• For area of 18-26m²
Tuya provides a series of service capabilities to help brands quickly complete the product intelligent、sales intelligent and service intelligent.
