Chinese Version,IN Standard,Brazil Standard,Chinese Standard,Japanese Standard,EU Standard,FR Standard,AU Standard,US Standard,British Version,UK Standard,Metering Version,General Version

Function Description

●2MP, two-way audio;
●Night vision mode: infrared light, white light dual light source, support night vision full color;
●Lens:3.6MM;
●support 128GTF card storage/cloud storage;
●Horizontal 355°,vertical 90°PTZ ;
●Support motion detection , Motion tracking, APP alarm information push;
● Support access to Alexa, Google Home (if needed) ;
● Working voltage: DC12V 2A, power consumption: 5W;
● Working environment: temperature 0 degrees -55 degrees; humidity 10%-90%;
● connection Method: mobile APP QR code distribution network, hotspot distribution network, WIFI quick connection, wired distribution network, etc.

Sales Area

Mainland, China,North America,South America,Europe,Southeast Asia,Middle East,Africa,Australia,Japan,South Korea,Asia,Hong Kong, China,Macao, China,Taiwan, China

Certification

CE,RoHS,FCC

Material

plastic

Package Size

226*200*120 mm

Product Size

160*150*80 mm

Net Weight

1000 g

Warranty

12 month

Packing List

* 720P/1080P Camera (No TF Card) X 1 * Bracket X 1 * Instructions X1 * Screw bag X1

Bulk Delivery

30 day

Power Supply Type

UK/US/EU/AU

IP Rating

Lens type

Prime lens

Aperture

F2.4

Field of View

horizontal 355 degrees,Vertical 90 degrees

Illumination Distance

Video Compression

H.264

Resolution

HD:1920*1080,1280*720

Network Interface

Wi-Fi

Frequency

2.4G

Pan&Tilt Angle

horizontal 355 degrees,Vertical 90 degrees

Storage

TF Card/Cloud

Tuya Cloud Storage

Yes

PIR Detection

Not support

Product on Sale Time

2020.9

Lens Focal Length

3.6

Day & Night Switch Mode

IR-cut filter with auto-switching

Max Resolution

1080P/2MP

Motion Detection

Support

Audio Exception Detection

Support

Human-body Detection

Support

Operating Conditions

-20~60c
