Wi-Fi Roller Shutter Motor

Popular
Min.Order:
1000 Pieces

Product modelWSER40

ProtocolWi-Fi

CertificationCCCULCERoHSREACHFCC

Product Length(mm)590

Product
Parameters
Overview
Smart Features

Product Parameters

Product model
WSER40
Product Category
Tubular Motor Curtain
Product Color
White
Market Specifications
Chinese Version(Neutral Packaging),British Version
Function Description
1.Silent motor 2.Electronic travel limit 3.Jog function 4, the third point limit 5. Control method: Tuya APP control, remote control control, can be connected to third-party smart speakers (Tmall Elf, Xiaodu, Xiaoai, Tencent Xiaowei, Ruoqi, Google)
Sales Area
Mainland, China,Europe,Africa,Australia
Certification
CCC,UL,CE,RoHS,REACH,FCC
Material
Steel
Package Size
650*73*73 mm
Product Size
590*35*35 mm
Packing Quantity
10
Packing List
1.Motor 2.Motor manual 3, Tuya APP distribution network operation guide 4.Warranty card 5. Certificate of conformity 6.Star mounting plate 7, L-shaped spring
Bulk Delivery
30 day
Power Supply Type
AC, DC
Rated Power(W)
103-155
Rated Voltage(V)
120-230
IP Rating
IP44
Product on Sale Time
2020
Rated Current(A)
0.49-0.88
Net Weight(KG)
1.34-1.4
Rated Torque(Nm)
10
output Speed(rpm)
14-28
Maximum Turns(Turn)
Product Length(mm)
590
Noise(dB)
28
Control Mode
Intelligent Agreement,Weak Current,Remote Control
Limit Set
The Third Intermediate Limit
Built-in Battery
No
Speed Adjustable Gears
1
Supported for Tilting to Adjust Light
Yes
Connect Voice Platforms

Value-added Services

Tuya provides a series of service capabilities to help brands quickly complete the product intelligent、sales intelligent and service intelligent.

Online Control Panel

The control panel is used to display and execute product functions. Users can control smart devices through the panel remotely.

This picture is an example of a mobile phone control interface. If you want to experience how the mobile phone controls this product.

Please use the "Tuya Smart" App to scan the QR code.

Tuya Smart-Me-Top Right Corner

Don't have Tuya Smart yet?
Download Now.

Method 1

Scan to Download

Method 2

Search TuyaSmart in App Store or
Android App Store to Download

Configure Device Panel

After OEM products,you can design and develop panels as needed,or you can use a wealth of custom components to configure beautiful and easy-to-use panels.
